The TruBlu™ Jr. is designed to upgrade your existing Edvotek® electrophoresis equipment to allow safe, real-time analysis of DNA fragments as they migrate through the agarose gel. This compact unit utilises the same blue light technology that is found in the EDGE™ and TruBlu™ 2 transilluminator for visualization of SYBR® Safe or other blue light-reactive dyes. The TruBlu™ Jr. can also be used to examine fluorescence from green fluorescent protein (GFP).
Features:
- Docks seamlessly with the Edvotek® M12 Electrophoresis System
- Includes orange contrast lid for M12 cover
- Includes orange contrast hood for TruBlu™ Jr.
- Battery operated for convenient use in the classroom
- Safe — non-UV wavelength
- Blue light emission spectrum centered around 470nm
- Viewing surface: 10 x 6cm
- Universal voltage for worldwide use
Specifications:
- LED wavelength: 470nm ± 10nm
- LED life: 50,000 hours
- Input voltage: 100-240V, 50/60 hz, 0.6A
- Output voltage: 5V DC, 0.5A
- Dimensions, w x l x h: 12 x 14 x 6cm
- Operating conditions: 4 to 37°C, 75% maximum humidity
